ARIZONA VORTEX v.1.0 during Advanced Skills Rescue Workshop in Oak Creek Canyon, AZ in 1998. Here, the AZV is being used as a modified easel A Frame to support a highline around a precipice of rock. The easel leg is very short in this case and the A frame is parallel to the highline.

A Frame

Click on photo to enlarge

ARIZONA VORTEX v.1.0 set up on sloping 900' highline during 2002 Canyon Rescue Workshop "Skunk Camp" in Grand Staircase Nat. Monument. Notice that this A Frame is held exclusively by the highline itself and requires no guying.

A Frame

Click on photo to enlarge

ARIZONA VORTEX v.1.0 used as a twin-guyed A Frame high directional during steep angle evacuation in Duluth, MN Team Skills Rescue Workshop in 2002.

SA Frame

Click on photo to enlarge

ARIZONA VORTEX v.1.0 used as a twin-guyed SA Frame above a confined space. All three legs were used on each side to facilitate the vertical-to-horizontal removal of full litter. A dynamic butt block was used (bottom left) to direct forces down on the bipod.
Duluth, MN Team Skills Rescue SemWorkshopinar

Lazy Leg SA Frame

Click on photo to enlarge

ARIZONA VORTEX v.1.0 used at the Grand Canyon in a modified "Lazy Leg" SA Frame application. The easel leg is used as the lazy leg to balance the SA Frame, hence, no guying is needed.
